use solid extrusion technology for sealing thoroughly, achieving a waterproof rating of IP67Pro.
60LEDs & 10Pixels per meter
DC24V constant voltage operation
The CCT of white can be customized as warm white or pure white or cool white
Product Parameter
| PN | S012060CC4ST(N1506-IP68) |
| Voltage | DC24V |
| LED Type | SMD5050 4 in 1 |
| LED Quantity | 60LEDs/m |
| Color | RGB+W:3000K/4000K/6500K |
| Dimension | 5000*15*6mm |
| Cutting unit | 100mm |
| Lumen/m | R:105 G:245 B:64 W:324Lm |
| Power | 19.2W/m |
| Control | SPI-UCS2904 |
| Pixel/M | 10 |
| IP Rating | IP67Pro |
| Material | FPC + silica gel |
| O.T | -25℃ ~ 60℃ |
