In drone and stage decoration lighting, visual impact depends on programmable pixel control, fast response, stable mounting, and reliable heat dissipation. This project adopts the P032 RGBW Digital LED Module (DC5V, SPI/SM16714) to create dynamic pixel animations such as gradients, chases, flashes, and segmented effects, while keeping a dedicated white channel for clean white illumination.
Key Highlights:
Pixel-level control: SPI protocol with SM16714 IC; compatible with SPI controllers or DMX systems via a decoder.
RGBW output: Full color + white (3000K/4000K/6000K options) to match different stage themes.
Secure mounting: Aluminum PCB with M3 mounting holes for rigid fixation on metal structures.
Thermal guidance (important): Install on a heat-dissipation plate/metal substrate (recommended backside aluminum heatsink contact area >100 cm²). Keep substrate temperature below 55°C at full brightness. No 3M tape—use thermally conductive adhesive. Avoid silicone sealants (e.g., glass glue).
Customization & delivery: Cable length/connectors can be customized; JST connectors included; anti-static packaging.
