This is an RGB side-emitting COB low-voltage LED strip supporting DC12V/DC24V power input and PWM dimming. With a 120° beam angle, it delivers a continuous, dot-free linear light effect, making it ideal for edge lighting, contour/outline ambient lighting, and decorative linear illumination. IP20 and IP65 versions are available. Supplied in 5m rolls and cuttable by segment, with wiring/termination customizable for your project.
S008630ZB3PZ(C) / S008630ZC3PZ(C) is an RGB side-emitting COB flexible strip solution designed for low-voltage systems (DC12V or DC24V) with PWM control. It provides a smooth linear appearance and strong “line-of-light” effect, especially suitable for applications where continuous lighting and limited installation space are required.
Key Benefits
Side-emitting linear effect: optimized for edge lighting and contour ambient lighting in showcases, cabinets and signage
PWM dimming compatible: easy integration with common RGB controllers for mood lighting control
Cuttable & easy to integrate: 5m roll; cut length 12V: 20mm / 24V: 50mm for precise fit
Multiple protection options: IP20 / IP65 available to match different environments
Key Specs (per datasheet)
Power: 9.6 W/m
Beam angle: 120°
Operating temperature: -25 to 60°C
Size: 5000 × 8 mm (roll)
Typical Applications
Refrigerated display edge lighting, retail showcases and shelving, lightbox/signage edge illumination, decorative contour lighting and other linear ambient lighting projects.
We can provide customization on length, lead wire/connector style, IP rating and assembly details, and supply related documents such as datasheets/IES (based on the actual version).
